Solid-Core
AS0-NOAC-24U FieldAdjustable,3-350mASetpointRange,24VAC/VDCPowered
AS0-NOAC-120 FieldAdjustable,3-350mASetpointRange,120VACPowered
AS0-NCAC-24U FieldAdjustable,3-350mASetpointRange,24VAC/VDCPowered
AS0-NCAC-120 FieldAdjustable,3-350mASetpointRange,120VACPowered
AS0-NODC-24U FieldAdjustable,3-350mASetpointRange,24VAC/VDCPowered
AS0-NODC-120 FieldAdjustable,3-350mASetpointRange,120VACPowered
AS0-NCDC-24U FieldAdjustable,3-350mASetpointRange,24VAC/VDCPowered
AS0-NCDC-120 FieldAdjustable,3-350mASetpointRange,120VACPowered
AS1Series,ACCurrentSwitches
Solid-Core
AS1-NOU-FF AdjustableSetpoint,1-150Amps,FrontTerminals,SmartLED
AS1-NOU-FF-NL AdjustableSetpoint,1-150Amps,FrontTerminals,w/oLED
AS1-NOU-FF-GO Fixed0.75AmpMaximumSetpoint,FrontTerminals,w/oLED
AS1-NOU-FT AdjustableSetpoint,1-150Amps,TopTerminals,SmartLED
AS1-NOU-FT-NL AdjustableSetpoint,1-150Amps,TopTerminals,w/oLED
AS1-NOU-FT-GO Fixed0.75AmpMaximumSetpoint,TopTerminals,w/oLED
AS1-NCU-FF AdjustableSetpoint,1-150Amps,FrontTerminals,SmartLED
AS1-NCU-FT AdjustableSetpoint,1-150Amps,TopTerminals,SmartLED
AS1-NCU-FT-NL AdjustableSetpoint,1-150Amps,TopTerminals,w/oLED
AS1-NCU-FT-GO Fixed0.75AmpMaximumSetpoint,TopTerminals,w/oLED
Split-Core
AS1-NOU-SP AdjustableSetpoint,1.5-150Amps,TopTerminals,SmartLED
AS1-NOU-SP-NL AdjustableSetpoint,1.5-150Amps,TopTerminals,w/oLED
AS1-NOU-SP-GO Fixed1.5AmpMaximumSetpoint,TopTerminals,w/oLED
AS1-NCU-SP AdjustableSetpoint,1.5-150Amps,TopTerminals,SmartLED
AS1-NCU-SP-NL AdjustableSetpoint,1.5-150Amps,TopTerminals,w/oLED
AS1-NCU-SP-GO Fixed1.5AmpMaximumSetpoint,TopTerminals,w/oLED
AS1Series,ACCurrentSwitcheswithHighOutputContactRating
Solid-Core
AS1-NOR-FT-GO Fixed5.8AmpMaximumSetpoint,TopTerminals,w/oLED
AS1Series,ACCurrentSwitcheswithOutputBypass
Solid-Core
AS1-NOU-FT-Y39 AdjustableSetpoint,1.5-150Amps,TopTerminals,SmartLED
AS1-NCU-FT-Y39 AdjustableSetpoint,1.5-150Amps,TopTerminals,SmartLED
AS1Series,ACCurrentSwitcheswithDualIndependentOutputs
Solid-Core
AS1-DODC-FL AdjustableSetpoint,0.75-20Amps,TopTerminals,SmartLED
AS2-DODC-FL AdjustableSetpoint,20-50Amps,TopTerminals,SmartLED
AS1Series,ACCurrentSwitchesinaCompactCase
Solid-Core
AS1-NOU-CC Fixed0.5AmpMaximumSetpoint,TopTerminalswith24"Leads
AS1-NCU-CC Fixed0.5AmpMaximumSetpoint,TopTerminalswith24"Leads
ACISeries,AMPFlasherACCurrentIndicator
Solid-Core
ACI-0.5-L FlashingLEDwithACcurrentover0.5A,maximum100A
ACI-0.5-P LEDmountedon24"leads
AS3-NOAC-FF AdjustableSetpoint,1-6,6-40&40-175AmpRanges,FrontTerminals,SmartLED
AS3-NOAC-FF-NL AdjustableSetpoint,1-6,6-40&40-175AmpRanges,FrontTerminals,w/oLED
AS3-NOAC-FF-15 AdjustableSetpoint,1-6,6-40&40-175AmpRanges,FrontTerminals,SmartLED
AS3-NOAC-FT AdjustableSetpoint,1-6,6-40&40-175AmpRanges,TopTerminals,SmartLED
AS3-NOAC-FT-03 AdjustableSetpoint,1-6,6-40&40-175AmpRanges,TopTerminals,SmartLED
AS3-NCAC-FF AdjustableSetpoint,1-6,6-40&40-175AmpRanges,FrontTerminals,SmartLED
AS3-NCAC-FF-NL AdjustableSetpoint,1-6,6-40&40-175AmpRanges,FrontTerminals,w/oLED
AS3-NCAC-FF-15 AdjustableSetpoint,1-6,6-40&40-175AmpRanges,FrontTerminals,SmartLED
AS3-NCAC-FT AdjustableSetpoint,1-6,6-40&40-175AmpRanges,TopTerminals,SmartLED
AS3-NCAC-FT-03 AdjustableSetpoint,1-6,6-40&40-175AmpRanges,TopTerminals,SmartLED
AS3-NODC-FF AdjustableSetpoint,1-6,6-40&40-175AmpRanges,FrontTerminals,SmartLED
AS3-NODC-FF-NL AdjustableSetpoint,1-6,6-40&40-175AmpRanges,FrontTerminals,w/oLED
AS3-NCDC-FF AdjustableSetpoint,1-6,6-40&40-175AmpRanges,FrontTerminals,SmartLED
AS3-AADC-FF AdjustableSetpoint,1-6,6-40&40-175AmpRanges,FrontTerminals,w/oLED
AS3-CCDC-FF AdjustableSetpoint,1-6,6-40&40-175AmpRanges,FrontTerminals,w/oLED
AS3-NOAC-SP AdjustableSetpoint,1-6,6-40&40-200AmpRanges,TopTerminals,SmartLED
AS3-NODC-SP AdjustableSetpoint,1-6,6-40&40-200AmpRanges,TopTerminals,SmartLED
AS3-NCAC-SP AdjustableSetpoint,1-6,6-40&40-200AmpRanges,TopTerminals,SmartLED
AS3-NCDC-SP AdjustableSetpoint,1-6,6-40&40-200AmpRanges,TopTerminals,SmartLED
ASLSeries,LinearyAdjustmentACCurrentSwitches
Solid-Core
ASL1-NOU-FF LinearAdjustableSetpoint,1-10Amps,FrontTerminals,SmartLED
ASL2-NOU-FF LinearAdjustableSetpoint,10-50Amps,FrontTerminals,SmartLED
ASL3-NOU-FF LinearAdjustableSetpoint,50-100Amps,FrontTerminals,SmartLED
ASL4-NOU-FF LinearAdjustableSetpoint,100-150Amps,FrontTerminals,SmartLED
ASL1-NCU-FF LinearAdjustableSetpoint,1-10Amps,FrontTerminals,SmartLED
ASL2-NCU-FF Linear Adjustable Setpoint, 10-50 Amps, Front Terminals, SmartLED
ASL3-NCU-FF Linear Adjustable Setpoint, 50-100 Amps, Front Terminals, SmartLED
ASL4-NCU-FF Linear Adjustable Setpoint, 100-150 Amps, Front Terminals, SmartLED
Split-Core
ASL1-NOU-SP Linear Adjustable Setpoint, 2-20 Amps, Top Terminals, SmartLED
ASL2-NOU-SP Linear Adjustable Setpoint, 20-50 Amps, Top Terminals, SmartLED
ASL3-NOU-SP Linear Adjustable Setpoint, 50-100 Amps, Top Terminals, SmartLED
ASL4-NOU-SP Linear Adjustable Setpoint, 100-150 Amps, Top Terminals, SmartLED
ASL1-NCU-SP Linear Adjustable Setpoint, 2-20 Amps, Top Terminals, SmartLED
ASL2-NCU-SP Linear Adjustable Setpoint, 20-50 Amps, Top Terminals, SmartLED
ASL3-NCU-SP Linear Adjustable Setpoint, 50-100 Amps, Top Terminals, SmartLED
ASL4-NCU-SP Linear Adjustable Setpoint, 100-150 Amps, Top Terminals, SmartLED
DS1 Series, DC Current Switches
Solid-Core
DS1-NODC-FF Fixed 0.75 Amp Maximum Setpoint, Top Terminals 10-28 VDC Powered
DS3 Series, DC Current Switches
Solid-Core
DS3-NOU-12U Adjustable Setpoint, 2-20, 10-50 & 20-100 Amp Ranges, Side Terminals, SmartLED, 12 VAC/VDC Powered
DS3-NOU-24U Adjustable Setpoint, 2-20, 10-50 & 20-100 Amp Ranges, Side Terminals, SmartLED, 24 VAC/VDC Powered
DS3-SDT-12U Adjustable Setpoint, 2-20, 10-50 & 20-100 Amp Ranges, Side Terminals, SmartLED, 12 VAC/VDC Powered
DS3-SDT-24U Adjustable Setpoint, 2-20, 10-50 & 20-100 Amp Ranges, Side Terminals, SmartLED, 24 VAC/VDC Powered
ASX-NOU-FT Adjustable Setpoint, 1.5-12, 12-55 & 50-175 Amp Ranges, Top Terminals, SmartLED
ASX-NOAC-FT Adjustable Setpoint, 1.5-12, 12-55 & 50-175 Amp Ranges, Top Terminals, SmartLED
ASX-NCU-FT Adjustable Setpoint, 1.5-12, 12-55 & 50-175 Amp Ranges, Top Terminals, SmartLED
ASX-NCAC-FT Adjustable Setpoint, 1.5-12, 12-55 & 50-175 Amp Ranges, Top Terminals, SmartLED
Split-Core
ASX-NOU-SP Adjustable Setpoint, 2-12, 12-55 & 50-200 Amp Ranges, Top Terminals, SmartLED
ASX-NOAC-SP Adjustable Setpoint, 2-12, 12-55 & 50-200 Amp Ranges, Top Terminals, SmartLED
ASX-NCU-SP Adjustable Setpoint, 2-12, 12-55 & 50-200 Amp Ranges, Top Terminals, SmartLED
ASX-NCAC-SP Adjustable Setpoint, 2-12, 12-55 & 50-200 Amp Ranges, Top Terminals, SmartLED
ASXP Series, Powered AC Current Switches with Time Delays
Solid-Core
ASXP1-SDT-24U-FL Adjustable Setpoint, 1-20 Amp Range, 24 VAC/VDC Powered
ASXP1-SDT-120-FL Adjustable Setpoint, 1-20 Amp Range, 120 VAC Powered
ASXP2-SDT-24U-FL Adjustable Setpoint, 20-50 Amp Range, 24 VAC/VDC Powered
ASXP2-SDT-120-FL Adjustable Setpoint, 20-50 Amp Range, 120 VAC Powered
ASXP3-SDT-24U-FL Adjustable Setpoint, 50-80 Amp Range, 24 VAC/VDC Powered
ASXP3-SDT-120-FL Adjustable Setpoint, 50-80 Amp Range, 120 VAC Powered
Split-Core
ASXP8-SDT-24U-LS Adjustable Setpoint, 200-800 Amp Range, 24 VAC/VDC Powered
ASXP8-SDT-120-LS Adjustable Setpoint, 200-800 Amp Range, 120 VAC Powered
ASXP10-SDT-24U-LS Adjustable Setpoint, 400-1000 Amp Range, 24 VAC/VDC Powered
ASXP10-SDT-120-LS Adjustable Setpoint, 400-1000 Amp Range, 120 VAC Powered
ASXP12-SDT-24U-LS Adjustable Setpoint, 600-1200 Amp Range, 24 VAC/VDC Powered
ASXP12-SDT-120-LS Adjustable Setpoint, 600-1200 Amp Range, 120 VAC Powered
ASXP16-SDT-24U-LS Adjustable Setpoint, 1000-1600 Amp Range, 24 VAC/VDC Powered
ASXP16-SDT-120-LS Adjustable Setpoint, 1000-1600 Amp Range, 120 VAC Powered
ASC Series, AC Current Switches, Factory-Calibrated
Solid-Core
ASC-NOU-5-FT-xxx* Factory Adjusted Setpoint, 2-150 A, Normally-Open, 50 Hz, Top Terminals
ASC-NOU-6-FT-xxx* Factory Adjusted Setpoint, 2-150 A, Normally-Open, 60 Hz, Top Terminals
ASC-NCU-5-FT-xxx* Factory Adjusted Setpoint, 2-150 A, Normally-Closed, 50 Hz, Top Terminals
ASC-NCU-6-FT-xxx* Factory Adjusted Setpoint, 2-150 A, Normally-Closed, 60 Hz, Top Terminals
Split-Core
ASC-NOU-5-SP-xxx* Factory Adjusted Setpoint, 3-150 A, Normally-Open, 50 Hz, Top Terminals
ASC-NOU-6-SP-xxx* Factory Adjusted Setpoint, 3-150 A, Normally-Open, 60 Hz, Top Terminals
ASC-NCU-5-SP-xxx* Factory Adjusted Setpoint, 3-150 A, Normally-Closed, 50 Hz, Top Terminals
ASC-NCU-6-SP-xxx* Factory Adjusted Setpoint, 3-150 A, Normally-Closed, 60 Hz, Top Terminals
ASC-NOU-5-FT-sss* 2-150A Factory-Calibrated Setpoint, 50 Hz, Top Terminals
ASC-NOU-6-FT-sss* 2-150A Factory-Calibrated Setpoint, 60 Hz, Top Terminals
ASC-NCU-5-FT-sss* 2-150A Factory-Calibrated Setpoint, 50 Hz, Top Terminals
ASC-NCU-6-FT-sss* 2-150A Factory-Calibrated Setpoint, 60 Hz, Top Terminals
Split-Core
ASC-NOU-5-SP-sss** 3-150A Factory-Calibrated Setpoint, 50 Hz, Top Terminals
ASC-NOU-6-SP-sss** 3-150A Factory-Calibrated Setpoint, 60 Hz, Top Terminals
ASC-NCU-5-SP-sss** 3-150A Factory-Calibrated Setpoint, 50 Hz, Top Terminals
ASC-NCU-6-SP-sss** 3-150A Factory-Calibrated Setpoint, 60 Hz, Top Terminals
ASM-NOU-OL-FT 1.5-150A Self Calibrating Setpoint, Overload Only, Top Terminals
ASM-NOU-OU-FT 1.5-150A Self Calibrating Setpoint, Over & Underload, Top Terminals
ASM-NOU-UL-FT 1.5-150A Self Calibrating Setpoint, Underload Only, Top Terminals
ASM-NCU-OL-FT 1.5-150A Self Calibrating Setpoint, Overload Only, Top Terminals
ASM-NCU-OU-FT 1.5-150A Self Calibrating Setpoint, Over & Underload, Top Terminals
ASM-NCU-UL-FT 1.5-150A Self Calibrating Setpoint, Underload Only, Top Terminals
Split-Core
ASM-NOU-OL-SP 2.5-150A Self Calibrating Setpoint, Overload Only, Top Terminals
ASM-NOU-OU-SP 2.5-150A Self Calibrating Setpoint, Over & Underload, Top Terminals
ASM-NOU-UL-SP 2.5-150A Self Calibrating Setpoint, Underload Only, Top Terminals
ASM-NCU-OL-SP 2.5-150A Self Calibrating Setpoint, Overload Only, Top Terminals
ASM-NCU-OU-SP 2.5-150A Self Calibrating Setpoint, Over & Underload, Top Terminals
ASM-NCU-UL-SP 2.5-150A Self Calibrating Setpoint, Underload Only, Top Terminals
ASD Series, AC Current Switches with Digital Display
ASD1-NOAC-24U-FL 0-50A Range, 24VAC/DC Power, Top Terminals
ASD1-NCAC-24U-FL 0-50A Range, 24VAC/DC Power, Top Terminals
ASD2-NOAC-24U-FL 0-200A Range, 24VAC/DC Power, Top Terminals
ASD2-NCAC-24U-FL 0-200A Range, 24VAC/DC Power, Top Terminals
AT0-420-24L-FF 0-2 & 0-5 Amp Ranges, Front Terminals
AT0-420-24L-FT 0-2 & 0-5 Amp Ranges, Top Terminals
AT1-005-000-FF 0-10, 0-20 & 0-50 Amp Ranges, Front Terminals
AT1-005-000-FT 0-10, 0-20 & 0-50 Amp Ranges, Top Terminals
AT1-010-000-FF 0-10, 0-20 & 0-50 Amp Ranges, Front Terminals
AT1-010-000-FT 0-10, 0-20 & 0-50 Amp Ranges, Top Terminals
AT1-420-24L-FF 0-10, 0-20 & 0-50 Amp Ranges, Front Terminals
AT1-420-24L-FT 0-10, 0-20 & 0-50 Amp Ranges, Top Terminals
AT2-005-000-FF 0-100, 0-150 & 0-200 Amp Ranges, Front Terminals
AT2-005-000-FT 0-100, 0-150 & 0-200 Amp Ranges, Top Terminals
AT2-010-000-FF 0-100, 0-150 & 0-200 Amp Ranges, Front Terminals
AT2-010-000-FT 0-100, 0-150 & 0-200 Amp Ranges, Top Terminals
AT2-420-24L-FF 0-100, 0-150 & 0-200 Amp Ranges, Front Terminals
AT2-420-24L-FT 0-100, 0-150 & 0-200 Amp Ranges, Top Terminals
AT2-420-24L-FL 0-100, 0-133 & 0-200 Amp Ranges, Base Terminals
AT3-420-24L-FL 0-375, 0-500 & 0-750 Amp Ranges, Base Terminals
AT4-420-24L-FL 0-1000, 0-1333 & 0-2000 Amp Ranges, Base Terminals
Split-Core 000 - Self-Powered, 24L - 24 VDC Loop-Powered
AT0-420-24L-SP 0-2 & 0-5 Amp Ranges, Top Terminals
AT1-005-000-SP 0-10, 0-20 & 0-50 Amp Ranges, Top Terminals
AT1-010-000-SP 0-10, 0-20 & 0-50 Amp Ranges, Top Terminals
AT1-420-24L-SP 0-10, 0-20, 0-50 Amp Ranges, Top Termnals
AT2-005-000-SP 0-100, 0-150 & 0-200 Amp Ranges, Top Terminals
AT2-010-000-SP 0-100, 0-150 & 0-200 Amp Ranges, Top Terminals
AT2-420-24L-SP 0-100, 0-150, 0-200 Amp Ranges, Top Terminals
ATR Series, True RMS Current Transducers
Solid-Core 24L - 24 VDC Loop-Powered
ATR0-420-24L-FT 0-2 & 0-5 Amp Ranges, Top Terminals
ATR1-420-24L-FT 0-10, 0-20 & 0-50 Amp Ranges, Top Terminals
ATR2-420-24L-FT 0-100, 0-150 & 0-200 Amp Ranges, Top Terminals
ATR2-420-24L-FL 0-100, 0-133 & 0-200 Amp Ranges, Base Terminals
ATR3-420-24L-FL 0-375, 0-500 & 0-750 Amp Ranges, Base Terminals
ATR4-420-24L-FL 0-1000, 0-1333 & 0-2000 Amp Ranges, Base Terminals
Split-Core 24L - 24 VDC Loop-Powered
ATR0-420-24L-SP 0-2 & 0-5 Amp Ranges, Top Terminals
ATR1-420-24L-SP 0-10, 0-20 & 0-50 Amp Ranges, Top Terminals
ATR2-420-24L-SP 0-100, 0-150 & 0-200 Amp Ranges, Top Terminals
AT-LS Series, erage Responding Current Transducers
Split-Core 24L - 24 VDC Loop-Powered
AT8-420-24L-LS 0-800 Amp Range, Base Terminals
AT10-420-24L-LS 0-1000 Amp Range, Base Terminals
AT12-420-24L-LS 0-1200 Amp Range, Base Terminals
AT16-420-24L-LS 0-1600 Amp Range, Base Terminals
ATR-LS Series, True RMS Current Transducers
Split-Core 24L - 24 VDC Loop-Powered
ATR8-420-24L-LS 0-800 Amp Range, Base Terminals
ATR10-420-24L-LS 0-1000 Amp Range, Base Terminals
ATR12-420-24L-LS 0-1200 Amp Range, Base Terminals
ATR16-420-24L-LS 0-1600 Amp Range, Base Terminals
ATCR Series, True RMS Flexible Loop Current Transducers
Split-Core 24L - 24 VDC Loop-Powered
ATCR1-420-24L-D 0-500 Amp Range, Base Terminals
ATCR2-420-24L-D 0-1000 Amp Range, Base Terminals
ATCR3-420-24L-D 0-1500 Amp Range, Base Terminals
ATCR4-420-24L-D 0-2000 Amp Range, Base Terminals
ATP0-005-24U-FF 0-2 & 0-5 Amp Ranges, Front Terminals 0-5 VDC
ATP0-010-24U-FF 0-2 & 0-5 Amp Ranges, Front Terminals 0-10 VDC
ATP0-420-24U-FF 0-2 & 0-5 Amp Ranges, Front Terminals 4-20 mA
ATP0-005-120-FF 0-2 & 0-5 Amp Ranges, Front Terminals 0-5 VDC
ATP0-010-120-FF 0-2 & 0-5 Amp Ranges, Front Terminals 0-10 VDC
ATP0-420-120-FF 0-2 & 0-5 Amp Ranges, Front Terminals 4-20 mA
ATP1-005-24U-FF 0-10, 0-20 & 0-50 Amp Ranges, Front Terminals 0-5 VDC
ATP1-010-24U-FF 0-10, 0-20 & 0-50 Amp Ranges, Front Terminals 0-10 VDC
ATP1-420-24U-FF 0-10, 0-20 & 0-50 Amp Ranges, Front Terminals 4-20 mA
ATP1-005-120-FF 0-10, 0-20 & 0-50 Amp Ranges, Front Terminals 0-5 VDC
ATP1-010-120-FF 0-10, 0-20 & 0-50 Amp Ranges, Front Terminals 0-10 VDC
ATP1-420-120-FF 0-10, 0-20 & 0-50 Amp Ranges, Front Terminals 4-20 mA
ATP2-005-24U-FF 0-100, 0-150 & 0-200 Amp Ranges, Front Terminals 0-5 VDC
ATP2-010-24U-FF 0-100, 0-150 & 0-200 Amp Ranges, Front Terminals 0-10 VDC
ATP2-420-24U-FF 0-100, 0-150 & 0-200 Amp Ranges, Front Terminals 4-20 mA
ATP2-005-120-FF 0-100, 0-150 & 0-200 Amp Ranges, Front Terminals 0-5 VDC
ATP2-010-120-FF 0-100, 0-150 & 0-200 Amp Ranges, Front Terminals 0-10 VDC
ATP2-420-120-FF 0-100, 0-150 & 0-200 Amp Ranges, Front Terminals 4-20 mA
Split-Core 24U - 24 VAC/VDC Powered, 120 - 120 VAC Powered
ATP0-005-24U-SP 0-2 & 0-5 Amp Ranges, Top Terminals 0-5 VDC
ATP0-010-24U-SP 0-2 & 0-5 Amp Ranges, Top Terminals 0-10 VDC
ATP0-420-24U-SP 0-2 & 0-5 Amp Ranges, Top Terminals 4-20 mA
ATP0-005-120-SP 0-2 & 0-5 Amp Ranges, Top Terminals 0-5 VDC
ATP0-010-120-SP 0-2 & 0-5 Amp Ranges, Top Terminals 0-10 VDC
ATP0-420-120-SP 0-2 & 0-5 Amp Ranges, Top Terminals 4-20 mA
ATP1-005-24U-SP 0-10, 0-20 & 0-50 Amp Ranges, Top Terminals 0-5 VDC
ATP1-010-24U-SP 0-10, 0-20 & 0-50 Amp Ranges, Top Terminals 0-10 VDC
ATP1-420-24U-SP 0-10, 0-20 & 0-50 Amp Ranges, Top Terminals 4-20 mA
ATP1-005-120-SP 0-10, 0-20 & 0-50 Amp Ranges, Top Terminals 0-5 VDC
ATP1-010-120-SP 0-10, 0-20 & 0-50 Amp Ranges, Top Terminals 0-10 VDC
ATP1-420-120-SP 0-10, 0-20 & 0-50 Amp Ranges, Top Terminals 4-20 mA
ATP2-005-24U-SP 0-100, 0-150 & 0-200 Amp Ranges, Top Terminals 0-5 VDC
ATP2-010-24U-SP 0-100, 0-150 & 0-200 Amp Ranges, Top Terminals 0-10 VDC
ATP2-420-24U-SP 0-100, 0-150 & 0-200 Amp Ranges, Top Terminals 4-20 mA
ATP2-005-120-SP 0-100, 0-150 & 0-200 Amp Ranges, Top Terminals 0-5 VDC
ATP2-010-120-SP 0-100, 0-150 & 0-200 Amp Ranges, Top Terminals 0-10 VDC
ATP2-420-120-SP 0-100, 0-150 & 0-200 Amp Ranges, Top Terminals 4-20 mA
ATPR Series, True RMS Current Transducers
Split-Core 24D - 24 VDC Powered
ATPR0-005-24D-SP 0-2 & 0-5 Amp Ranges, Top Terminals 0-5 VDC
ATPR0-010-24D-SP 0-2 & 0-5 Amp Ranges, Top Terminals 0-10 VDC
ATPR1-005-24D-SP 0-10, 0-20 & 0-50 Amp Ranges, Top Terminals 0-5 VDC
ATPR1-010-24D-SP 0-10, 0-20 & 0-50 Amp Ranges, Top Terminals 0-10 VDC
ATPR2-005-24D-SP 0-100, 0-150 & 0-200 Amp Ranges, Top Terminals 0-5 VDC
ATPR2-010-24D-SP 0-100, 0-150 & 0-200 Amp Ranges, Top Terminals 0-10 VDC
ATH Series, Time Integration Current Transducers
Solid-Core 24U - 24 VAC/DC Powered
ATH0-005-24U-FL 0-2 & 0-5 Amp Ranges, Top Terminals 0-5 VDC
ATH0-010-24U-FL 0-2 & 0-5 Amp Ranges, Top Terminals 0-10 VDC
ATH0-420-24U-FL 0-2 & 0-5 Amp Ranges, Top Terminals 4-20 mA
ATH1-005-24U-FL 0-10, 0-20 & 0-50 Amp Ranges, Top Terminals 0-5 VDC
ATH1-010-24U-FL 0-10, 0-20 & 0-50 Amp Ranges, Top Terminals 0-10 VDC
ATH1-420-24U-FL 0-10, 0-20 & 0-50 Amp Ranges, Top Terminals 4-20 mA
ATH2-005-24U-FL 0-100, 0-150 & 0-200 Amp Ranges, Top Terminals 0-5 VDC
ATH2-010-24U-FL 0-100, 0-150 & 0-200 Amp Ranges, Top Terminals 0-10 VDC
ATH2-420-24U-FL 0-100, 0-150 & 0-200 Amp Ranges, Top Terminals 4-20 mA
120 - 120 VAC Powered
ATH0-005-120-FL 0-2 & 0-5 Amp Ranges, Top Terminals 0-5 VDC
ATH0-010-120-FL 0-2 & 0-5 Amp Ranges, Top Terminals 0-10 VDC
ATH0-420-120-FL 0-2 & 0-5 Amp Ranges, Top Terminals 4-20 mA
ATH1-005-120-FL 0-10, 0-20 & 0-50 Amp Ranges, Top Terminals 0-5 VDC
ATH1-010-120-FL 0-10, 0-20 & 0-50 Amp Ranges, Top Terminals 0-10 VDC
ATH1-420-120-FL 0-10, 0-20 & 0-50 Amp Ranges, Top Terminals 4-20 mA
ATH2-005-120-FL 0-100, 0-150 & 0-200 Amp Ranges, Top Terminals 0-5 VDC
ATH2-010-120-FL 0-100, 0-150 & 0-200 Amp Ranges, Top Terminals 0-10 VDC
ATH2-420-120-FL 0-100, 0-150 & 0-200 Amp Ranges, Top Terminals 4-20 mA
Split-Core 24U - 24 VAC or VDC Powered
ATH0-005-24U-SP 0-2 & 0-5 Amp Ranges, Top Terminals 0-5 VDC
ATH0-010-24U-SP 0-2 & 0-5 Amp Ranges, Top Terminals 0-10 VDC
ATH0-420-24U-SP 0-2 & 0-5 Amp Ranges, Top Terminals 4-20 mA
ATH1-005-24U-SP 0-10, 0-20 & 0-50 Amp Ranges, Top Terminals 0-5 VDC
ATH1-010-24U-SP 0-10, 0-20 & 0-50 Amp Ranges, Top Terminals 0-10 VDC
ATH1-420-24U-SP 0-10, 0-20 & 0-50 Amp Ranges, Top Terminals 4-20 mA
ATH2-005-24U-SP 0-100, 0-150 & 0-200 Amp Ranges, Top Terminals 0-5 VDC
ATH2-010-24U-SP 0-100, 0-150 & 0-200 Amp Ranges, Top Terminals 0-10 VDC
ATH2-420-24U-SP 0-100, 0-150 & 0-200 Amp Ranges, Top Terminals 4-20 mA
ATP3-005-24U-FL 0-375, 0-500 & 0-750 Amp Ranges, Base Terminals
ATP3-010-24U-FL 0-375, 0-500 & 0-750 Amp Ranges, Base Terminals
ATP3-420-24U-FL 0-375, 0-500 & 0-750 Amp Ranges, Base Terminals
ATP3-005-120-FL 0-375, 0-500 & 0-750 Amp Ranges, Base Terminals
ATP3-010-120-FL 0-375, 0-500 & 0-750 Amp Ranges, Base Terminals
ATP3-420-120-FL 0-375, 0-500 & 0-750 Amp Ranges, Base Terminals
ATP4-005-24U-FL 0-1000, 0-1333 & 0-2000 Amp Ranges, Base Terminals
ATP4-010-24U-FL 0-1000, 0-1333 & 0-2000 Amp Ranges, Base Terminals
ATP4-420-24U-FL 0-1000, 0-1333 & 0-2000 Amp Ranges, Base Terminals
ATP4-005-120-FL 0-1000, 0-1333 & 0-2000 Amp Ranges, Base Terminals
ATP4-010-120-FL 0-1000, 0-1333 & 0-2000 Amp Ranges, Base Terminals
ATP4-420-120-FL 0-1000, 0-1333 & 0-2000 Amp Ranges, Base Terminals
Solid-Core 24U - 24 VAC/VDC Powered, 120 - 120 VAC Powered
ATPR3-005-24U-FL 0-375, 0-500 & 0-750 Amp Ranges, Base Terminals
ATPR3-010-24U-FL 0-375, 0-500 & 0-750 Amp Ranges, Base Terminals
ATPR3-420-24U-FL 0-375, 0-500 & 0-750 Amp Ranges, Base Terminals
ATPR3-005-120-FL 0-375, 0-500 & 0-750 Amp Ranges, Base Terminals
ATPR3-010-120-FL 0-375, 0-500 & 0-750 Amp Ranges, Base Terminals
ATPR3-420-120-FL 0-375, 0-500 & 0-750 Amp Ranges, Base Terminals
ATPR4-005-24U-FL 0-1000, 0-1333 & 0-2000 Amp Ranges, Base Terminals
ATPR4-010-24U-FL 0-1000, 0-1333 & 0-2000 Amp Ranges, Base Terminals
ATPR4-420-24U-FL 0-1000, 0-1333 & 0-2000 Amp Ranges, Base Terminals
ATPR4-005-120-FL 0-1000, 0-1333 & 0-2000 Amp Ranges, Base Terminals
ATPR4-010-120-FL 0-1000, 0-1333 & 0-2000 Amp Ranges, Base Terminals
ATPR4-420-120-FL 0-1000, 0-1333 & 0-2000 Amp Ranges, Base Terminals
Split-Core 24U - 24 VAC/VDC Powered
ATQ0-05K-24U-SP 0-2, 0-5A Ranges
ATQ1-05K-24U-SP 0-10, 0-20, 0-50A Ranges
ATQ2-05K-24U-SP 0-100, 0-150, 0-200A Ranges
ATQ0-10K-24U-SP 0-2, 0-5A Ranges
ATQ1-10K-24U-SP 0-10, 0-20, 0-50A Ranges
ATQ2-10K-24U-SP 0-100, 0-150, 0-200A Ranges
ATS-420-SDT-24D-DL 0-1200 Amp Input, DIN Rail Case
120 - 120 VAC Powered
ATS-420-SDT-120-DL 0-1200 Amp Input, DIN Rail Case
ATS1-005-NOAC-24U-FL 0-50A Range, 24VAC/DC Power
ATS1-005-NCAC-24U-FL 0-50A Range, 24VAC/DC Power
ATS1-010-NOAC-24U-FL 0-50A Range, 24VAC/DC Power
ATS1-010-NCAC-24U-FL 0-50A Range, 24VAC/DC Power
ATS1-420-NOAC-24U-FL 0-50A Range, 24VAC/DC Power
ATS1-420-NCAC-24U-FL 0-50A Range, 24VAC/DC Power
ATS2-005-NOAC-24U-FL 0-200A Range, 24VAC/DC Power
ATS2-005-NCAC-24U-FL 0-200A Range, 24VAC/DC Power
ATS2-010-NOAC-24U-FL 0-200A Range, 24VAC/DC Power
ATS2-010-NCAC-24U-FL 0-200A Range, 24VAC/DC Power
ATS2-420-NOAC-24U-FL 0-200A Range, 24VAC/DC Power
ATS2-420-NCAC-24U-FL 0-200A Range, 24VAC/DC Power
DT0-out*-ppp**-U-FL 0-5, 0-10 & 0-20 Amp Ranges, 24 VAC/VDC or 120 VAC Powered
DT1-out*-ppp**-U-FL 0-50, 0-75 & 0-100 Amp Ranges, 24 VAC/VDC or 120 VAC Powered
DT2-out*-ppp**-U-FL 0-100, 0-150 & 0-200 Amp Ranges, 24 VAC/VDC or 120 VAC Powered
Split-Core
DT1-out*-24U-U-SP 0-50, 0-75 & 0-100 Amp Ranges, 24 VAC/VDC Powered
DT1-out*-24U-U-SP 0-50, 0-75 & 0-100 Amp Ranges, 24 VAC/VDC Powered
DT2-out*-24U-U-SP 0-100, 0-150 & 0-200 Amp Ranges, 24 VAC/VDC Powered
DT2-out*-24U-U-SP 0-100, 0-150 & 0-200 Amp Ranges, 24 VAC/VDC Powered
DT3-out*-24U-U-SP 0-150, 0-225 & 0-300 Amp Ranges, 24 VAC/VDC Powered
DT3-out*-24U-U-SP 0-150, 0-225 & 0-300 Amp Ranges, 24 VAC/VDC Powered
DT4-out*-24U-U-SP 0-200, 0-300 & 0-400 Amp Ranges, 24 VAC/VDC Powered
DT4-out*-24U-U-SP 0-200, 0-300 & 0-400 Amp Ranges, 24 VAC/VDC Powered
DT Series DC Current Transducers, Bipolar Output
Solid-Core
DT0-out*-ppp**-BP-FL 0-5, 0-10 & 0-20 Amp Ranges, 24 VAC/VDC or 120 VAC Powered
DT1-out*-ppp**-BP-FL 0-50, 0-75 & 0-100 Amp Ranges, 24 VAC/VDC or 120 VAC Powered
DT2-out*-ppp**-BP-FL 0-100, 0-150 & 0-200 Amp Ranges, 24 VAC/VDC or 120 VAC Powered
DT1-out*-24U-BP-SP 0-50, 0-75 & 0-100 Amp Ranges, 24 VAC/VDC Powered
DT2-out*-24U-BP-SP 0-100, 0-150 & 0-200 Amp Ranges, 24 VAC/VDC Powered
DT3-out*-24U-BP-SP 0-150, 0-225 & 0-300 Amp Ranges, 24 VAC/VDC Powered
DT4-out*-24U-BP-SP 0-200, 0-300 & 0-400 Amp Ranges, 24 VAC/VDC Powered
DT1-010-24U-BD-SP 0-100 Amp Ranges, 24 VAC/VDC Powered, -/+10 VDC Output
DT2-010-24U-BD-SP 0-200 Amp Ranges, 24 VAC/VDC Powered, -/+10 VDC Output
DT3-010-24U-BD-SP 0-300 Amp Ranges, 24 VAC/VDC Powered, -/+10 VDC Output
DT4-010-24U-BD-SP 0-400 Amp Ranges, 24 VAC/VDC Powered, -/+10 VDC Output
DT5-out*-ppp**-U-DL 0-300 Amp Range, 24 VAC/VDC or 120 VAC Powered
DT6-out*-ppp**-U-DL 0-500 Amp Range, 24 VAC/VDC or 120 VAC Powered
DT7-out*-ppp**-U-DL 0-750 Amp Range, 24 VAC/VDC or 120 VAC Powered
DT8-out*-ppp**-U-DL 0-1000 Amp Range, 24 VAC/VDC or 120 VAC Powered
DT9-out*-ppp**-U-DL 0-1200 Amp Range, 24 VAC/VDC or 120 VAC Powered
DT5-out*-ppp**-BP-DL 0-300 Amp Range, 24 VAC/VDC or 120 VAC Powered
DT6-out*-ppp**-BP-DL 0-500 Amp Range, 24 VAC/VDC or 120 VAC Powered
DT7-out*-ppp**-BP-DL 0-750 Amp Range, 24 VAC/VDC or 120 VAC Powered
DT8-out*-ppp**-BP-DL 0-1000 Amp Range, 24 VAC/VDC or 120 VAC Powered
DT9-out*-ppp**-BP-DL 0-1200 Amp Range, 24 VAC/VDC or 120 VAC Powered
DTB-out*-ppp**-U-SP 0-50 Amp Range, 5 VDC or 12 VDC Powered
DTC-out*-ppp**-U-SP 0-100 Amp Range, 5 VDC or 12 VDC Powered
DLTA-420-24L-U-FF 0-20 Amp range, 24 VDC Loop-Powered
DLTB-420-24L-U-FF 0-50 Amp range, 24 VDC Loop-Powered
DLTC-420-24L-U-FF 0-100 Amp range, 24 VDC Loop-Powered
Split-Core
DLTB-420-24L-U-SP 0-50 Amp range, 24 VDC Loop-Powered
DLTC-420-24L-U-SP 0-100 Amp range, 24 VDC Loop-Powered
DLTD-420-24L-U-SP 0-200 Amp range, 24 VDC Loop-Powered
DLTE-420-24L-U-SP 0-300 Amp range, 24 VDC Loop-Powered
DLTF-420-24L-U-SP 0-400 Amp range, 24 VDC Loop-Powered
DLTA-420-24L-BP-FF 0-20 Amp range, 24 VDC Loop-Powered
DLTB-420-24L-BP-FF 0-50 Amp range, 24 VDC Loop-Powered
DLTC-420-24L-BP-FF 0-100 Amp range, 24 VDC Loop-Powered
Split-Core
DLTB-420-24L-BP-SP 0-50 Amp range, 24 VDC Loop-Powered
DLTC-420-24L-BP-SP 0-100 Amp range, 24 VDC Loop-Powered
DLTD-420-24L-BP-SP 0-200 Amp range, 24 VDC Loop-Powered
DLTE-420-24L-BP-SP 0-300 Amp range, 24 VDC Loop-Powered
DLTF-420-24L-BP-SP 0-400 Amp range, 24 VDC Loop-Powered
DTB-005-24D-U-FF 0-50 Amp Range, 24 VDC powered
DTB-010-24D-U-FF 0-50 Amp Range, 24 VDC powered
DTC-005-24D-U-FF 0-100 Amp Range, 24 VDC powered
DTC-010-24D-U-FF 0-100 Amp Range, 24 VDC powered
AG1-NOAC-ppp*-FS-sss** Factory Adjusted Setpoint, 5-100 mA, Normally Energized, Top Terminals
AG1-NOAC-ppp*-NF-sss** Factory Adjusted Setpoint, 5-100 mA, Normally De-Energized, Top Terminals
AG1-NCAC-ppp*-FS-sss** Factory Adjusted Setpoint, 5-100 mA, Normally Energized, Top Terminals
AG1-NCAC-ppp*-NF-sss** Factory Adjusted Setpoint, 5-100 mA, Normally De-Energized, Top Terminals
AG1-NODC-ppp*-FS-sss** Factory Adjusted Setpoint, 5-100 mA, Normally Energized, Top Terminals
AG1-NODC-ppp*-NF-sss** Factory Adjusted Setpoint, 5-100 mA, Normally De-Energized, Top Terminals
AG1-NCDC-ppp*-FS-sss** Factory Adjusted Setpoint, 5-100 mA, Normally Energized, Top Terminals
AG1-NCDC-ppp*-NF-sss** Factory Adjusted Setpoint, 5-100 mA, Normally De-Energized, Top Terminals
AG2-NOAC-ppp*-FS-sss** Factory Adjusted Setpoint, 80-950 mA, Normally Energized, Top Terminals
AG2-NOAC-ppp*-NF-sss** Factory Adjusted Setpoint, 80-950 mA, Normally De-Energized, Top Terminals
AG2-NCAC-ppp*-FS-sss** Factory Adjusted Setpoint, 80-950 mA, Normally Energized, Top Terminals
AG2-NCAC-ppp*-NF-sss** Factory Adjusted Setpoint, 80-950 mA, Normally De-Energized, Top Terminals
AG2-NODC-ppp*-FS-sss** Factory Adjusted Setpoint, 80-950 mA, Normally Energized, Top Terminals
AG2-NODC-ppp*-NF-sss** Factory Adjusted Setpoint, 80-950 mA, Normally De-Energized, Top Terminals
AG2-NCDC-ppp*-FS-sss** Factory Adjusted Setpoint, 80-950 mA, Normally Energized, Top Terminals
AG2-NCDC-ppp*-NF-sss** Factory Adjusted Setpoint, 80-950 mA, Normally De-Energized, Top Terminals
AG3-NOAC-ppp*-FS-TR3 Jumper Select 5, 10 or 30 mA Setpoint, Normally Energized, Top Terminals
AG3-NOAC-ppp*-NF-TR3 Jumper Select 5, 10 or 30 mA Setpoint, Normally De-Energized, Top Terminals
AG3-NCAC-ppp*-FS-TR3 Jumper Select 5, 10 or 30 mA Setpoint, Normally Energized, Top Terminals
AG3-NCAC-ppp*-NF-TR3 Jumper Select 5, 10 or 30 mA Setpoint, Normally De-Energized, Top Terminals
AG3-NODC-ppp*-FS-TR3 Jumper Select 5, 10 or 30 mA Setpoint, Normally Energized, Top Terminals
AG3-NODC-ppp*-NF-TR3 Jumper Select 5, 10 or 30 mA Setpoint, Normally De-Energized, Top Terminals
AG3-NCDC-ppp*-FS-TR3 Jumper Select 5, 10 or 30 mA Setpoint, Normally Energized, Top Terminals
AG3-NCDC-ppp*-NF-TR3 Jumper Select 5, 10 or 30 mA Setpoint, Normally De-Energized, Top Terminals
AG1-NOR1-24U-LA-sss* Factory Adjusted Setpoint, 5-100 mA, Latching, Top Terminals
AG1-NOR1-120-LA-sss* Factory Adjusted Setpoint, 5-100 mA, Latching, Top Terminals
AG1-NCR1-24U-LA-sss* Factory Adjusted Setpoint, 5-100 mA, Latching, Top Terminals
AG1-NCR1-120-LA-sss* Factory Adjusted Setpoint, 5-100 mA, Latching, Top Terminals
AG1-SDT1-24U-ENE-sss* Factory Adjusted Setpoint, 5-100 mA, Normally Energized, Top Terminals
AG1-SDT1-24U-DEN-sss* Factory Adjusted Setpoint, 5-100 mA, Normally De-Energized, Top Terminals
AG1-SDT1-120-ENE-sss* Factory Adjusted Setpoint, 5-100 mA, Normally Energized, Top Terminals
AG1-SDT1-120-DEN-sss* Factory Adjusted Setpoint, 5-100 mA, Normally De-Energized, Top Terminals
AG2-NOR1-24U-LA-sss* Factory Adjusted Setpoint, 80-950 mA, Latching, Top Terminals
AG2-NOR1-120-LA-sss* Factory Adjusted Setpoint, 80-950 mA, Latching, Top Terminals
AG2-NCR1-24U-LA-sss* Factory Adjusted Setpoint, 80-950 mA, Latching, Top Terminals
AG2-NCR1-120-LA-sss* Factory Adjusted Setpoint, 80-950 mA, Latching, Top Terminals
AG2-SDT1-24U-ENE-sss* Factory Adjusted Setpoint, 80-950 mA, Normally Energized, Top Terminals
AG2-SDT1-24U-DEN-sss* Factory Adjusted Setpoint, 80-950 mA, Normally De-Energized, Top Terminals
AG2-SDT1-120-ENE-sss* Factory Adjusted Setpoint, 80-950 mA, Normally Energized, Top Terminals
AG2-SDT1-120-DEN-sss* Factory Adjusted Setpoint, 80-950 mA, Normally De-Energized, Top Terminals
AG3-NOR1-24U-LA-TR3 Jumper Select 5, 10 or 30 mA Setpoint, Latching, Top Terminals
AG3-NOR1-120-LA-TR3 Jumper Select 5, 10 or 30 mA Setpoint, Latching, Top Terminals
AG3-NCR1-24U-LA-TR3 Jumper Select 5, 10 or 30 mA Setpoint, Latching, Top Terminals
AG3-NCR1-120-LA-TR3 Jumper Select 5, 10 or 30 mA Setpoint, Latching, Top Terminals
AG3-SDT1-24U-ENE-TR3 Jumper Select 5, 10 or 30 mA Setpoint, Normally Energized, Top Terminals
AG3-SDT1-24U-DEN-TR3 Jumper Select 5, 10 or 30 mA Setpoint, Normally De-Energized, Top Terminals
AG3-SDT1-120-ENE-TR3 Jumper Select 5, 10 or 30 mA Setpoint, Normally Energized, Top Terminals
AG3-SDT1-120-DEN-TR3 Jumper Select 5, 10 or 30 mA Setpoint, Normally De-Energized, Top Terminals
AGT1-420-24L-FL 0-50 mA Range, Top Terminals
AGT2-420-24L-FL 0-100 mA Range, Top Terminals
AGL1-NOR1-24U-LA-sss* Factory Adjusted Setpoint, 5-100 mA, Latching, Base Terminals
AGL1-NOR1-120-LA-sss* Factory Adjusted Setpoint, 5-100 mA, Latching, Base Terminals
AGL1-NCR1-24U-LA-sss* Factory Adjusted Setpoint, 5-100 mA, Latching, Base Terminals
AGL1-NCR1-120-LA-sss* Factory Adjusted Setpoint, 5-100 mA, Latching, Base Terminals
AGL1-SDT1-24U-ENE-sss* Factory Adjusted Setpoint, 5-100 mA, Normally Energized, Base Terminals
AGL1-SDT1-24U-DEN-sss* Factory Adjusted Setpoint, 5-100 mA, Normally De-Energized, Base Terminals
AGL1-SDT1-120-ENE-sss* Factory Adjusted Setpoint, 5-100 mA, Normally Energized, Base Terminals
AGL1-SDT1-120-DEN-sss* Factory Adjusted Setpoint, 5-100 mA, Normally De-Energized, Base Terminals
AGL2-NOR1-24U-LA-sss* Factory Adjusted Setpoint, 80-950 mA, Latching, Base Terminals
AGL2-NOR1-120-LA-sss* Factory Adjusted Setpoint, 80-950 mA, Latching, Base Terminals
AGL2-NCR1-24U-LA-sss* Factory Adjusted Setpoint, 80-950 mA, Latching, Base Terminals
AGL2-NCR1-120-LA-sss* Factory Adjusted Setpoint, 80-950 mA, Latching, Base Terminals
AGL2-SDT1-24U-ENE-sss* Factory Adjusted Setpoint, 80-950 mA, Normally Energized, Base Terminals
AGL2-SDT1-24U-DEN-sss* Factory Adjusted Setpoint, 80-950 mA, Normally De-Energized, Base Terminals
AGL2-SDT1-120-ENE-sss* Factory Adjusted Setpoint, 80-950 mA, Normally Energized, Base Terminals
AGL2-SDT1-120-DEN-sss* Factory Adjusted Setpoint, 80-950 mA, Normally De-Energized, Base Terminals
AGL3-NOR1-24U-LA-TR3 Jumper Select 5, 10 or 30 mA Setpoint, Latching, Base Terminals
AGL3-NOR1-120-LA-TR3 Jumper Select 5, 10 or 30 mA Setpoint, Latching, Base Terminals
AGL3-NCR1-24U-LA-TR3 Jumper Select 5, 10 or 30 mA Setpoint, Latching, Base Terminals
AGL3-NCR1-120-LA-TR3 Jumper Select 5, 10 or 30 mA Setpoint, Latching, Base Terminals
AGL3-SDT1-24U-ENE-TR3 Jumper Select 5, 10 or 30 mA Setpoint, Normally Energized, Base Terminals
AGL3-SDT1-24U-DEN-TR3 Jumper Select 5, 10 or 30 mA Setpoint, Normally De-Energized, Base Terminals
AGL3-SDT1-120-ENE-TR3 Jumper Select 5, 10 or 30 mA Setpoint, Normally Energized, Base Terminals
AGL3-SDT1-120-DEN-TR3 Jumper Select 5, 10 or 30 mA Setpoint, Normally De-Energized, Base Terminals
APS1-420-24L-0.5 0.5 kW @ 120 VAC
APS1-420-24L-0.75 0.75 kW @ 120 VAC
APS1-420-24L-1.0 1.0 kW @ 120 VAC
APS1-420-24L-5.0 5.0 kW @ 120 VAC
APS1-420-24L-10.0 10.0 kW @ 120 VAC
240 VAC Input
APS2-420-24L-0.5 0.5 kW @ 240 VAC
APS2-420-24L-0.75 0.75 kW @ 240 VAC
APS2-420-24L-1.0 1.0 kW @ 240 VAC
APS2-420-24L-5.0 5.0 kW @ 240 VAC
APS2-420-24L-10.0 10.0 kW @ 240 VAC
APS2-420-24L-20.0 20.0 kW @ 240 VAC
480 VAC Input
APS4-420-24L-5.0 5.0 kW @ 480 VAC
APS4-420-24L-10.0 10.0 kW @ 480 VAC
APS4-420-24L-20.0 20.0 kW @ 480 VAC
APS4-420-24L-50.0 50.0 kW @ 480 VAC
APS4-420-24L-75.0 75.0 kW @ 480 VAC
APS4-420-24L-100.0 100.0 kW @ 480 VAC
600 VAC Input
APS6-420-24L-5.0 5.0 kW @ 600 VAC
APS6-420-24L-10.0 10.0 kW @ 600 VAC
APS6-420-24L-20.0 20.0 kW @ 600 VAC
APS6-420-24L-50.0 50.0 kW @ 600 VAC
APS6-420-24L-75.0 75.0 kW @ 600 VAC
APS6-420-24L-100.0 100.0 kW @ 600 VAC
APN-600-MV-24U-MOD 600 VAC Max., ProteCT? Current Transformer Input
APN-600-5A-24U-MOD 600 VAC Max., 5 Amp Current Transformer Input
120 - 120 VAC Powered
APN-600-MV-120-MOD 600 VAC Max., ProteCT? Current Transformer Input
APN-600-5A-120-MOD 600 VAC Max., 5 Amp Current Transformer Input
240 - 240 VAC Powered
APN-600-MV-240-MOD 600 VAC Max., ProteCT? Current Transformer Input
APN-600-5A-240-MOD 600 VAC Max., 5 Amp Current Transformer Input
Note: Current transformers are not included
24U - 24 VAC/DC Powered
APN-600-RC1-24U-MOD 600 VAC Max., 0-500 Amp flexible CTs included
APN-600-RC2-24U-MOD 600 VAC Max., 0-2000 Amp flexible CTs included
120 - 120 VAC Powered
APN-600-RC1-120-MOD 600 VAC Max., 0-500 Amp flexible CTs included
APN-600-RC2-120-MOD 600 VAC Max., 0-2000 Amp flexible CTs included
240 - 240 VAC Powered
APN-600-RC1-240-MOD 600 VAC Max., 0-500 Amp flexible CTs included
APN-600-RC2-240-MOD 600 VAC Max., 0-2000 Amp flexible CTs included
APT-120-5A-24U-005 120 VAC System, 0-5 VDC Output
APT-120-5A-24U-010 120 VAC System, 0-10 VDC Output
APT-120-5A-24U-420 120 VAC System, 4-20 mA Output
APT-240-5A-24U-005 240 VAC System, 0-5 VDC Output
APT-240-5A-24U-010 240 VAC System, 0-10 VDC Output
APT-240-5A-24U-420 240 VAC System, 4-20 mA Output
APT-480-5A-24U-005 480 VAC System, 0-5 VDC Output
APT-480-5A-24U-010 480 VAC System, 0-10 VDC Output
APT-480-5A-24U-420 480 VAC System, 4-20 mA Output
APT-600-5A-24U-005 600 VAC System, 0-5 VDC Output
APT-600-5A-24U-010 600 VAC System, 0-10 VDC Output
APT-600-5A-24U-420 600 VAC System, 4-20 mA Output
APT-120-5A-120-005 120 VAC System, 0-5 VDC Output
APT-120-5A-120-010 120 VAC System, 0-10 VDC Output
APT-120-5A-120-420 120 VAC System, 4-20 mA Output
APT-240-5A-120-005 240 VAC System, 0-5 VDC Output
APT-240-5A-120-010 240 VAC System, 0-10 VDC Output
APT-240-5A-120-420 240 VAC System, 4-20 mA Output
APT-480-5A-120-005 480 VAC System, 0-5 VDC Output
APT-480-5A-120-010 480 VAC System, 0-10 VDC Output
APT-480-5A-120-420 480 VAC System, 4-20 mA Output
APT-600-5A-120-005 600 VAC System, 0-5 VDC Output
APT-600-5A-120-010 600 VAC System, 0-10 VDC Output
APT-600-5A-120-420 600 VAC System, 4-20 mA Output
APT-120-5A-240-005 120 VAC System, 0-5 VDC Output
APT-120-5A-240-010 120 VAC System, 0-10 VDC Output
APT-120-5A-240-420 120 VAC System, 4-20 mA Output
APT-240-5A-240-005 240 VAC System, 0-5 VDC Output
APT-240-5A-240-010 240 VAC System, 0-10 VDC Output
APT-240-5A-240-420 240 VAC System, 4-20 mA Output
APT-480-5A-240-005 480 VAC System, 0-5 VDC Output
APT-480-5A-240-010 480 VAC System, 0-10 VDC Output
APT-480-5A-240-420 480 VAC System, 4-20 mA Output
APT-600-5A-240-005 600 VAC System, 0-5 VDC Output
APT-600-5A-240-010 600 VAC System, 0-10 VDC Output
APT-600-5A-240-420 600 VAC System, 4-20 mA Output
APT-120-MV-24U-005 120 VAC System, 0-5 VDC Output
APT-120-MV-24U-010 120 VAC System, 0-10 VDC Output
APT-120-MV-24U-420 120 VAC System, 4-20 mA Output
APT-240-MV-24U-005 240 VAC System, 0-5 VDC Output
APT-240-MV-24U-010 240 VAC System, 0-10 VDC Output
APT-240-MV-24U-420 240 VAC System, 4-20 mA Output
APT-480-MV-24U-005 480 VAC System, 0-5 VDC Output
APT-480-MV-24U-010 480 VAC System, 0-10 VDC Output
APT-480-MV-24U-420 480 VAC System, 4-20 mA Output
APT-600-MV-24U-005 600 VAC System, 0-5 VDC Output
APT-600-MV-24U-010 600 VAC System, 0-10 VDC Output
APT-600-MV-24U-420 600 VAC System, 4-20 mA Output
APT-120-MV-120-005 120 VAC System, 0-5 VDC Output
APT-120-MV-120-010 120 VAC System, 0-10 VDC Output
APT-120-MV-120-420 120 VAC System, 4-20 mA Output
APT-240-MV-120-005 240 VAC System, 0-5 VDC Output
APT-240-MV-120-010 240 VAC System, 0-10 VDC Output
APT-240-MV-120-420 240 VAC System, 4-20 mA Output
APT-480-MV-120-005 480 VAC System, 0-5 VDC Output
APT-480-MV-120-010 480 VAC System, 0-10 VDC Output
APT-480-MV-120-420 480 VAC System, 4-20 mA Output
APT-600-MV-120-005 600 VAC System, 0-5 VDC Output
APT-600-MV-120-010 600 VAC System, 0-10 VDC Output
APT-600-MV-120-420 600 VAC System, 4-20 mA Output
APT-120-MV-240-005 120 VAC System, 0-5 VDC Output
APT-120-MV-240-010 120 VAC System, 0-10 VDC Output
APT-120-MV-240-420 120 VAC System, 4-20 mA Output
APT-240-MV-240-005 240 VAC System, 0-5 VDC Output
APT-240-MV-240-010 240 VAC System, 0-10 VDC Output
APT-240-MV-240-420 240 VAC System, 4-20 mA Output
APT-480-MV-240-005 480 VAC System, 0-5 VDC Output
APT-480-MV-240-010 480 VAC System, 0-10 VDC Output
APT-480-MV-240-420 480 VAC System, 4-20 mA Output
APT-600-MV-240-005 600 VAC System, 0-5 VDC Output
APT-600-MV-240-010 600 VAC System, 0-10 VDC Output
APT-600-MV-240-420 600 VAC System, 4-20 mA Output
CTC333-420-24L-DIN 0-0.333 VAC CT Input, DIN Rail Case
CTC05A-420-24L-DIN 0-5 Amp CT Input, DIN Rail Case
ADC1-420-120-MOD-DIN Eight 4-20 mA Loop-Powered Inputs
ADC2-420-120-MOD-DIN Four 4-20 mA Loop-Powered & Four External Powered Inputs
ADC3-420-120-MOD-DIN Eight 4-20 mA External-Powered Inputs
ADC1-420-240-MOD-DIN Eight 4-20 mA Loop-Powered Inputs
ADC2-420-240-MOD-DIN Four 4-20 mA Loop-Powered & Four External Powered Inputs
ADC3-420-240-MOD-DIN Eight 4-20 mA External-Powered Inputs
ADC1-420-24D-MOD-DIN Eight 4-20 mA Loop-Powered Inputs
ADC2-420-24D-MOD-DIN Four 4-20 mA Loop-Powered & Four External Powered Inputs
ADC3-420-24D-MOD-DIN Eight 4-20 mA External-Powered Inputs
WRT-R85-05D-C Wireless Transmitter & Receiver, RS485 ModBus RTU Output
VTR1-420-24L-DIN True RMS Voltage Transducer, 120 VAC Nominal Range
VTR2-420-24L-DIN True RMS Voltage Transducer, 150 VAC Nominal Range
VTR3-420-24L-DIN True RMS Voltage Transducer, 240 VAC Nominal Range
VTR4-420-24L-DIN True RMS Voltage Transducer, 480 VAC Nominal Range
VTR5-420-24L-DIN True RMS Voltage Transducer, 500 VAC Nominal Range
VTR6-420-24L-DIN True RMS Voltage Transducer, 600 VAC Nominal Range
VTD Series DC Voltage
VTD0-420-24U-DIN DC Voltage Ttransducer, 0-15 VDC Range
VTD1-420-24U-DIN DC Voltage Ttransducer, 0-25 VDC Range
VTD2-420-24U-DIN DC Voltage Ttransducer, 0-50 VDC Range
VTD3-420-24U-DIN DC Voltage Ttransducer, 0-150 VDC Range
VTD4-420-24U-DIN DC Voltage Ttransducer, 0-300 VDC Range
VTD5-420-24U-DIN DC Voltage Ttransducer, 0-600 VDC Range
PBR Series, PowerBASE Relay
PBR-10C-12U PowerBASE realy, 12 VAC/VDC Coil
PBR-10C-24U PowerBASE realy, 24 VAC/VDC Coil
DIN Rail Adapters
DIN-2 DIN Rail Adapters, 2 clips & 2 screws
DINKIT Slotted DIN Rail, 2 end stops
NKP-075-005-SP 5 Amp Input
NKP-075-015-SP 15 Amp Input
NKP-075-030-SP 30 Amp Input
NKP-075-050-SP 50 Amp Input
NKP-075-070-SP 70 Amp Input
NKP-075-101-SP 100 Amp Input
NKP-075-151-SP 150 Amp Input
NKP-075-201-SP 200 Amp Input
CTP-075-005-SP 5 Amp Input
CTP-075-015-SP 15 Amp Input
CTP-075-030-SP 30 Amp Input
CTP-075-050-SP 50 Amp Input
CTP-075-070-SP 70 Amp Input
CTP-075-101-SP 100 Amp Input
CTP-075-151-SP 150 Amp Input
CTP-125-101-SP 100 Amp Input
CTP-125-151-SP 150 Amp Input
CTP-125-201-SP 200 Amp Input
CTP-125-251-SP 250 Amp Input
CTP-125-301-SP 300 Amp Input
CTP-125-401-SP 400 Amp Input
CTP-125-601-SP 600 Amp Input
CTP-200-601-SP 600 Amp Input
CTP-200-801-SP 800 Amp Input
CTP-200-102-SP 1000 Amp Input
CTP-200-122-SP 1200 Amp Input
CTP-200-152-SP 1500 Amp Input
CTRC-333-500-24U-D 500 Amp Input
CTRC-333-1000-24U-D 1000 Amp Input
CTRC-333-1500-24U-D 1500 Amp Input
CTRC-333-2000-24U-D 2000 Amp Input
2RL500-NK 50:5
2RL101-NK 100:5
2RL151-NK 150:5
2RL201-NK 200:5
2RL251-NK 250:5
2RL301-NK 300:5
5RL500-NK 50:5
5RL101-NK 100:5
5RL151-NK 150:5
5RL201-NK 200:5
5RL251-NK 250:5
5RL301-NK 300:5
5RL401-NK 400:5
5RL501-NK 500:5
5RL601-NK 600:5
5RL801-NK 800:5
5RL102-NK 1000:5
5RL122-NK 1200:5
7RL500-NK 50:5
7RL101-NK 100:5
7RL151-NK 150:5
7RL201-NK 200:5
7RL251-NK 250:5
7RL301-NK 300:5
7RL401-NK 400:5
7RL501-NK 500:5
7RL601-NK 600:5
7RL801-NK 800:5
7RL102-NK 1000:5
7RL122-NK 1200:5
7RL152-NK 1500:5
7RL162-NK 1600:5
2SFT500-NK 50:5
2SFT101-NK 100:5
2SFT151-NK 150:5
2SFT201-NK 200:5
2SFT251-NK 250:5
2SFT301-NK 300:5
5SFT500-NK 50:5
5SFT101-NK 100:5
5SFT151-NK 150:5
5SFT201-NK 200:5
5SFT251-NK 250:5
5SFT301-NK 300:5
5SFT401-NK 400:5
5SFT501-NK 500:5
5SFT601-NK 600:5
5SFT801-NK 800:5
5SFT102-NK 1000:5
5SFT122-NK 1200:5
7SFT500-NK 50:5
7SFT101-NK 100:5
7SFT151-NK 150:5
7SFT201-NK 200:5
7SFT251-NK 250:5
7SFT301-NK 300:5
7SFT401-NK 400:5
7SFT501-NK 500:5
7SFT601-NK 600:5
7SFT801-NK 800:5
7SFT102-NK 1000:5
7SFT122-NK 1200:5
7SFT152-NK 1500:5
7SFT162-NK 1600:5
1SP-100-00-L36-NK 100:5
1SP-150-00-L36-NK 150:5
1SP-200-00-L36-NK 200:5
1SP-250-00-L36-NK 250:5
1SP-300-00-L36-NK 300:5
1SP-400-00-L36-NK 400:5
3SP-100-00-L36-NK 100:5
3SP-200-00-L36-NK 200:5
3SP-300-00-L36-NK 300:5
3SP-400-00-L36-NK 400:5
3SP-500-00-L36-NK 500:5
3SP-600-00-L36-NK 600:5
3SP-800-00-L36-NK 800:5
3SP-1000-00-L36-NK 1000:5
3SP-1200-00-L36-NK 1200:5
3SP-1500-00-L36-NK 1500:5
3SP-2000-00-L36-NK 2000:5
5SP-400-00-L36-NK 400:5
5SP-500-00-L36-NK 500:5
5SP-600-00-L36-NK 600:5
5SP-800-00-L36-NK 800:5
5SP-1000-00-L36-NK 1000:5
5SP-1200-00-L36-NK 1200:5
5SP-1500-00-L36-NK 1500:5
5SP-2000-00-L36-NK 2000:5
7SP-600-00-L36-NK 600:5
7SP-800-00-L36-NK 800:5
7SP-1000-00-L36-NK 1000:5
7SP-1200-00-L36-NK 1200:5
7SP-1500-00-L36-NK 1500:5
7SP-1600-00-L36-NK 1600:5
7SP-2000-00-L36-NK 2000:5
WC2-200-RA005 200:5
WC2-300-RA005 300:5
WC2-400-RA005 400:5
WC4-100-RA005 100:5
WC4-200-RA005 200:5
WC4-300-RA005 300:5
WC4-400-RA005 400:5
WC5-200-RA005 200:5
WC5-400-RA005 400:5
WC5-600-RA005 600:5
WC5-800-RA005 800:5
WC5-1000-RA005 1000:5
WC6-600-RA005 600:5
WC6-800-RA005 800:5
WC6-1000-RA005 1000:5
WC6-1200-RA005 1200:5
WC6-1600-RA005 1600:5
WC6-1800-RA005 1800:5
WC6-2000-RA005 2000:5
600-401-NK 400:5
600-501-NK 500:5
600-601-NK 600:5
600-801-NK 800:5
600-102-NK 1000:5
600-122-NK 1200:5
600-152-NK 1500:5
600-162-NK 1600:5
600-202-NK 2000:5
601-401-NK 400:5
601-501-NK 500:5
601-601-NK 600:5
601-801-NK 800:5
601-102-NK 1000:5
601-122-NK 1200:5
601-152-NK 1500:5
601-162-NK 1600:5
601-202-NK 2000:5
500T-041X071-401-NK 400:5
500T-041X071-501-NK 500:5
500T-041X071-601-NK 600:5
500T-041X071-801-NK 800:5
500T-041X071-102-NK 1000:5
500T-041X071-122-NK 1200:5
500T-041X071-152-NK 1500:5
500T-041X071-162-NK 1600:5
500T-041X071-202-NK 2000:5
500T-041X071-252-NK 2500:5
500T-041X071-302-NK 3000:5
500T-041X071-502-NK 5000:5
A100-1
Sentry 100-1
Sentry 100-1L
A100-3
Sentry 100-3
Sentry 100-3L
A100-2
Sentry 100-2
Sentry 100-2L
A100-4
Sentry 100-4
Sentry 100-4L
SA100-1
Sentry SC100-1
Sentry SC100-1L
SA100-2
Sentry SC100-2
Sentry SC100-2L
SA100-3
Sentry SC100-3
Sentry SC100-3L
SA100-4
Sentry SC100-4
Sentry SC100-4L
Sentry 200-05
Sentry 200-05-V
A200-1
Sentry 200-1
Sentry 200-1-V
A200-2
Sentry 200-2
Sentry 200-2-V
Sentry 200-3
Sentry 200-3-V
Sentry 200-4
Sentry 200-4-V
Sentry SC200-05
Sentry SC200-05-V
SA200-1
Sentry SC200-1
Sentry SC200-1-V
SA200-2
Sentry SC200-2
Sentry SC200-2-V
Current Operated Switches
Old Model
PD75
D150-1A
D150-1A
Sentry 225
Sentry 245
Sentry 250
D225
D245
D250
D150-2A
D150-3A
D150-NC
D150-NC
Sentry 250-NC
SD150
SD150
Sentry SC225
Sentry SC245
Sentry SC250
SD150-NC
SD150-NC
PD50
D100AC-NO-A
D100AC-NO-A-NL
D100AC-NC-A
SD100
SD100-NC
Sentry 500
Sentry SC500
Ground Fault Sensors
Old Model
GF1AC-NO
GF1AC-NC
GF1DC-NO
GF1DC-NC
Note: AG1-SDT1-ppp-DEN-sss can replace all of the above, all UL Recognized
GF2 Series were originally labeled "Failsafe". The "-FS" option provides the same operation.
GF2AC-NO
GF2AC-NC
GF2DC-NO
GF2DC-NC
GF1 & GF2 Model Numbers did not include 'wildcard' fields for power supply or setpoint. AG Model Numbers specify these variables.
Be sure you he the correct power supply and setpoint before ordering an AG Series to replace a GF1 or GF2 Series sensor.
Note: AG1-SDT1-ppp-ENE-sss can replace all of the above, all UL Recognized
AG Series 'wildcard' fields.
"ppp" Power
"sss" Setpoint.
Old Model
GF3NO-1-ppp-sss
GF3NO-3-ppp
GF3NC-1-ppp-sss
GF3NC-3-ppp
GF4 Series were originally labeled "Failsafe". The "-FS" option provides the same operation.
GF4NO-1-ppp-sss
GF4NO-3-ppp
GF4NC-1-ppp-sss
GF4NC-3-ppp
None
N/A
AT1-005-000-FF
AT1-005-000-FT
AT1-005-000-FT
N/A
AT1-010-000-FF
AT1-010-000-FT
AT1-010-000-FT
N/A
AT2-005-000-FF
AT2-005-000-FT
AT2-005-000-FT
N/A
AT2-010-000-FF
AT2-010-000-FT
AT2-010-000-FT
N/A
AT1-005-000-SP
AT1-005-000-SP
AT1-005-000-SP
N/A
AT2-005-000-SP
AT2-005-000-SP
AT2-005-000-SP
N/A
AT1-010-000-SP
AT1-010-000-SP
AT1-010-000-SP
N/A
AT2-010-000-SP
AT2-010-000-SP
AT2-010-000-SP
AT0-420-24L-FT
ATR0-420-24L-FT
AT1-420-24L-FF
AT1-420-24L-FT
ATR1-420-24L-FT
AT2-420-24L-FF
AT2-420-24L-FT
ATR2-420-24L-FT
AT3-420-24L-FL
ATR3-420-24L-FL
AT4-420-24L-FL
ATR4-420-24L-FL
AT0-420-24L-SP
ATR0-420-24L-SP
AT1-420-24L-SP
AT1-420-24L-SP
ATR1-420-24L-SP
AT2-420-24L-SP
AT2-420-24L-SP
ATR2-420-24L-SP
New Models
AS3-NODC-FF
AS3-NODC-FF
AS1-NOU-FF
AS1-NOU-FT-GO
AS1-NOU-FT-NL
AS1-NOU-FT
AS1-NOU-FF-GO
AS1-NOU-FF-NL
AS1-NOU-FF
All models above can replace this D150-1A variant:
AS3-AADC-FF
AS3-CCDC-FF
AS3-NCDC-FF
AS1-NCU-FF
AS1-NCU-FT
All three models above can replace this D150-NC variant:
AS3-NODC-SP
AS1-NOU-SP
AS1-NOU-SP-GO
AS1-NOU-SP-NL
AS1-NOU-SP
Both models above can replace this SD150 variant:
AS3-NCDC-SP
AS1-NCU-SP
Both models above can replace this SD150-NC variant:
AS3-NOAC-FF
AS3-NOAC-FF
AS3-NOAC-FF replaces these D100AC-NO variants:
AS3-NOAC-FF-NL
AS3-NCAC-FF
AS3-NCAC-FF replaces this D100AC-NC variant:
AS3-NOAC-SP
AS3-NOAC-SP replaces this SD100AC variant:
AS3-NCAC-SP
ASM-NOU-OU-FT
ASM-NOU-OU-SP
New Models
AG1-NOAC-120-NF-sss
AG1-NOAC-ppp-NF-sss
AG2-NOAC-ppp-NF-sss
AG1-NCAC-120-NF-sss
AG1-NCAC-ppp-NF-sss
AG2-NCAC-ppp-NF-sss
AG1-NODC-120-NF-sss
AG1-NODC-ppp-NF-sss
AG2-NODC-ppp-NF-sss
AG1-NCDC-120-NF-sss
AG1-NCDC-ppp-NF-sss
AG2-NCDC-ppp-NF-sss
AG1-NOAC-120-FS-sss
AG1-NOAC-ppp-FS-sss
AG2-NOAC-ppp-FS-sss
AG1-NCAC-120-FS-sss
AG1-NCAC-ppp-FS-sss
AG2-NCAC-ppp-FS-sss
AG1-NODC-120-FS-sss
AG1-NODC-ppp-FS-sss
AG2-NODC-ppp-FS-sss
AG1-NCDC-120-FS-sss
AG2-NCDC-ppp-FS-sss
Choose your power supply: 24U = 24 VDC/AC, 120 = 120 VAC, 200 = 200 VAC, 240 = 240 VAC
The setpoint is factory adjusted and covered (field adjustment possible). Insert the desired setpoint (see below).
AG1 Series:
AG2 Series:
New Models
AG1-NOR-ppp-NF-sss
AG2-NOR-ppp-NF-sss
AG2-NOR-ppp-NF-TR3
AG1-NCR-ppp-NF-sss
AG2-NCR-ppp-NF-sss
AG2-NCR-ppp-NF-TR3
AG1-NOR-ppp-FS-sss
AG2-NOR-ppp-FS-sss
AG2-NOR-ppp-FS-TR3
AG1-NCR-ppp-FS-sss
AG2-NCR-ppp-FS-sss
AG2-NCR-ppp-FS-TR3
AG1-CR1-ppp-LA-sss
AG2-CR2-ppp-LA-sss
AG3-CR1-ppp-LA-sss
2015年NKTECHNOLOGIES工廠上海航歐中國區銷售
NK technologies電流互感器NK technologies煙霧報警器NK technologies指示燈NK technologies傳感器NK technologies電流傳感器NK technologies接地故障傳感器NK technologies變送器NK technologies檢測開關NK technologies繼電器NK technologies轉換開關NK technologies電流變送器NK technologies變換器NK technologies濕度傳感器NK technologies油位傳感器NK technologies接頭
