| CPU | - LGA1700 socket 13th/12th Gen Intel? Core? i9/i7/i5/i3 & Celeron? processor (35W/65W)
|
| Chipset | |
| System Memory | - 2 x 262-pin DDR5-4800 SO-DIMM, up to 64GB
|
| BIOS | |
| COM | - 2 x RS-232/422/485 with autoflow
- 2 x RS-232
|
| USB | - 2 x USB 3.2 Gen1
- 4 x USB 3.2 Gen2
|
| Ethernet/PoE | - 3 x 2.5 GbE (Intel? i226-IT)
- 1 x GbE LAN (Intel? i219-LM)
- 4 PoE by request (PoE IEEE802.3at, up to 60W)
|
| Display | - 2 x HDMI 1.4b (1 x lockable)
- 1 x DisplayPort 1.4a
- 2 x DisplayPort 1.4a via optional MXM kit
|
| Digital I/O | |
| Audio | - 1 x Audio (MIC-in/Line-out); by request
|
| Storage | - 2 x 2.5" SATA HDD/SSD (up to 15 mm height; RAID 0,1 supported)
- 1 x NVMe by M.2 Key M 2280
- 1 x mSATA (enable in BIOS setting)
|
| Expansion | - 1 x Full-size PCI Express Mini Card slot (USB 2.0 + PCIe + SIM + mSATA signal)
- 1 x M.2 Key M 2280 socket (for storage)
- 1 x M.2 Key E 2230 socket (for Wi-Fi 6E)
- 1 x M.2 Key B 3052 socket (for 5G)
- 1 x Internal SIM slot for PCIe Mini Card slot
- 1 x MXM3.1 type A connector
- 1 x Flexible IO window (Default: 2 x DB9 half-cut bracket)
|
| Others | - TPM 2.0
- 1 x Power button
- 1 x Remote switch
- 1 x Front access SIM slot with cover (for M.2 Key B)
- 1 x Reset switch connector
- 5 x Antenna opening
- 1 x Grounding screw
|
| Power | - 9 to 36 VDC with ACC ignition
- 1 x Phoenix type VDC power input connector
|
| Watchdog Timer | - 255 levels, 1 to 255 sec.
|
| Construction | - Aluminum extrusion and heavy-duty steel, IP40
|
| Operating Temperature | - Without MXM module:
- -40°C to +65°C (-40°F to +140°F) (with W.T. DRAM & SSD, CPU TDP 35W)
- -40°C to +55°C (-40°F to +122°F) (with W.T. DRAM & SSD, CPU TDP 65W)
- With MXM module:
- -40°C to +55°C (-40°F to +122°F) (with W.T. DRAM & SSD & MXM kit, CPU TDP 35W)
|
| Relative Humidity | - 10% - 90%, non-condensing
|
| Vibration | - IEC 60068-2-64 (w/ SSD: 3Grms STD, random, 5 - 500 Hz, 1 hr/axis)
|
| Shock | - IEC 60068-2-27 (w/ SSD: 50G, half-sine, 11 ms duration)
|
Dimensions
(W x D x H) | - 280 mm (11.02") (W) x 210 mm (8.26") (D) x 80.5 mm (3.16") (H)
|
| Weight (net/gross) | - 4.9 kg (10.8 lb)/7 kg (15.43 lb)
|
| Certifications | |
| EOS Support | - Win 10 IoT, Win 11 IoT, Linux
|
| Software Support | |
| Mounting | - Wall mount kit
- DIN-rail kit
|
